Bike Hanger.. Overengineered!? What? Pfft!!

Betsy

Old School Grand Master
When we moved to our current house i made an oak bike shed with a living roof large enough to to store 2x bikes. Last xmas my kid was getting a shiney new Norco so i took one of the bike's to work. I have enough room in the cellar for at least 10 bikes but i live nr a river and the water table means the cellar floor is always damp.. anyhow long/short 4 days after xmas my commuter and my kids new Norco were stolen (f'kin cnuts!) made worse because it wasn't insured and it was special order so i could'nt just click my fingers and turn my boy's frown upside down.

...back to the thread title, since then.. i don't store any bikes outside, i keep them all at work so when i get home i stick my commuter under the bike shed and take it in the house when my mrs and kid have gone to bed. At the weekend i needed somewhere to hang it.
At the top of the cellar stairs there's a spot so i worked out the angle from the bars, past the pedals to the back tyre, this way there was still enough room to walk up and down the cellar stairs.
I made a wooden model with an angle which follows the desired position.

..with a loose section spot glued in place with a couple of spots of superglue
..built a little frame around the loose end section
..mixed some polyurethane
..poured it into the frame, trying not to get it over the edges while simultaneously looking through the camera :rolleyes:
..removed the resin mould
..removed the loose section
..drilled some holes under the loose section
...coated the mould with mould release solution

..tbc..

..mixed some rubberised resin
..put the mould back into position over the bracket with what was the loose section, now a cavity within the mould, poured in the liquid rubber, waited for it to cure and removed the mould, now the top tube can sit on a soft surface.
Dropped the rubber below the surface so it doesn't peal.
..super-bling chrome hinge offended my sensibilities
..so i rubbed it down with some wirewool and inserted and it into the brackets.
..added a little roller catch to hold it to the wall when not in use
..and there you have it, the world's most overengineered bike hanger.
..painted the back with white paint to cover up the holes which i cast through

..poured what was left of the rubber into yogurt pots to make some soft pads and stuck them to the wall with contact adhesive.

..fin

Me too!

I took a few sheets home from work a few months ago and made my kid a desk, well it's my take on a console table/dest with curved legs.

..replaced the shitty old balustrade while i was at it.
fullsizeoutput_31d5.jpeg IMG_2686.JPG

..the holes let light through and the cat likes to perch on the plinth
